UniFi 6 Long-Range Access Point
U6-LR is a High-Performance Access Point leveraging advanced WiFi 6 technology to provide powerful wireless
coverage to enterprise environments.
It delivers an aggregate radio rate of up to 3.0 Gbps with 5 GHz WiFi 6 (4x4 MU-MIMO and OFDMA) and 2.4 GHz
4x4 MIMO radios. The U6-LR seamlessly blends into any environment, and is capable of being mounted in indoor
and semi-outdoor environments (IP54 rated), and comes equipped with a Bluetooth Low Energy Radio for location-based services.
Mechanical
|
Dimensions |
Ø220 x 48 mm (Ø8.66 x 1.89") |
|
Weight |
Without Mount: 800 g (1.76 lb)
With Mount: 930 g (2.05 lb) |
|
|
|
|
|
Enclosure Material |
plastic |
|
Mounting Material |
SGCC Steel |
|
Weatherproong |
IP54 |
Hardware
|
Processor |
Specs Dual-Core ® Cortex ® A53 at 1.35 GHz |
|
Memory Information |
512 MB |
|
ManagementInterface |
Ethernet |
|
Networking Interface |
1 Gbps Ethernet RJ45 |
|
Button |
Factory Reset |
|
LED |
RGB |
|
Power Method |
PoE+, Passive PoE (48V) |
|
Power Supply |
UniFi PoE Switch 48V, 0.5A PoE Adapter (NotIncluded) |
|
Supported Voltage |
Range 44 to 57VDC |
|
Max. Power Consumption |
16.5W |
|
Max. TX Power |
2.4 GHz 26 dBm 2.4 GHz 26 dBm |
|
|
|
MIMO |
2.4 GHz 4 x 4 5 GHz 4 x 4 |
|
Throughput Speeds |
2.4 GHz 600 Mbps 5 GHz 2400 Mbps |
|
Antenna Gain |
2.4 GHz 4 dBi 5 GHz 5.5 dBi |
|
Mounting Wall/Ceiling |
(Kits Included) |
|
Operating Temperature |
-30 to 60° C (-22 to 140° F) |
|
Operating Humidity |
5 - 95% Noncondensing |
|
Certifications |
CE, FCC, IC |
