SPECIFICATIONS
-
Model
EC16
-
Fingerprint Capacity
30,000
-
Card Capacity
100,000
-
Communication
TCP/IP ,USB Host ,Wiegand,RS485,
-
Transaction Capacity
200,000
-
Floor Button Control Relay
16 Dual Relay
-
Number of Ports
2 TCP/IP, 2 Wiegand (26/34/66 bits),
1 RS485 (OSDP), 1 RS485 (expansion board),
1 Open, 1 close, 1 AUX output,
1 AUX in, 1 voice output(coming soon),
1 LED Output(COMMRUN/PWR/GND),
1 FIRE,1 Emergency, 1 Power in,
1 USB 2.0 port
-
Additional Info
Dimension(L*W): 165*230mm
Operating Temperature: -20°C to 55°C
Storage Temperature: -25°C to 65°C
Operating Humidity: 10% to 90% RH
Data Protection: AES256, HTTPS, TLS1.2
-
Special Functions
Protocol: ZKTeco A & C Push
Supported QR Code Reader : QR500/600 Series
RS485 address Set by DIP switch
Max Supported Expansion Board: 7pcs (DEX16)
over RS485
-
Certifications
CE, FCC, ISO9001, ISO14001
-
Compatibility
ZKBio CVSecurity
-
Power Supply
DC 12V 3A
-
Model
DEX16
-
Floor Button Control Relay
16 Dual Relay
-
Number of Ports
1 RS485 IN,
1 RS458 OUT
-
Communication
RS485(OSDP)
-
Additional Info
Communication to EC16 : RS485
Operating Temperature :-20°C to 55°C
Storage Temperature: -25°C to 65°C
Operating Humidity:10% to 90% RH
Dimension(L*W):165*160mm
-
Certifications
CE, FCC, ISO9001, ISO14001
-
Compatibility
ZKBio CVSecurity
-
Power Supply
DC 12V 1A
