2pcs - Video Balun cat5 Cable Passive Video Transceiver

PKR 0.00

Product details of 2pcs - Video Balun CAT5 Cable Passive Video Transceiver

Solution for transmitting CCTV video at distance up to 1200-9000ft through CAT5 cable

High quality image

Outstanding interference rejection

Transient protection

Enables cable cost cost up to 30%-50%

Operation temperature: -40C ~ +85C

Humidity: 0-98% (non-condensing)

Brand: China

Categories: Cctv Camera Accessories

The device is capable of receiving and transmitting video signals over UTP wire without using the power supply.
Enables cost-effective, point ot point transmission appliance. Adopts Twisted Pair Wiring, proving low cost and easily obtainable.
Provides noise interference restrainn design and permitting stable images.
The Max receiving and transmitting distance is 600M.
Built-in transcient protection design, needless to use a ground connection.

Specifications:

Power In	Not Required
Video IN/OUT	BNC (Male)
Transmission Distance	Max.600M (BW)
VIdeo Format	NTSC/PAL/CCIR/ SECAM
Operation Frequency Range	DC--10MHz
Twisted Pair Connector	One Pin Connector
Common Mode Rejection	70db
Input Impedance	75ohms
Output Impedance	100ohms
Wire Type	UTP Category 3,4, 5, 5e or 6 UTP 2-24WG or Better
