LB 12
PKR 0.00
The electric mortise lock is electronically controlled. A mortise lock is a mechanism that sits inside the door. Wiring electricity into the mechanical system uses an electrical impulse from the wiring to stick out a bolt into the door frame to lock the door. When the power is off, the clip will retract, and unlock the door.
LBB-1, LBB-2, and UBB-1 are accessories that help install electric mortise locks, namely, LB12, LB22, and LB35, on glass doors.
Brand: zkteco
Categories: Smart Lock Accessories
Parameter
| Model | LB12 | LB22 | LB35 |
| Photo |
 |
 |
 |
| Operating Voltage | DC 10V to 24V | DC 10V to 24V | DC 10V to 24V |
| Current |
Starting: 1A ± 10%
Operating: 110mA ± 10%
|
Starting: 1A ± 10%
Operating: 110mA ± 10%
|
Starting: 1A ±10%
Operating: 110mA ±10%
|
| Electrical Impulse |
ON: Lock
OFF: Unlock
|
ON: Lock
OFF: Unlock
|
ON: Lock
OFF: Unlock
|
| Wiring |
2 wire
Regardless + or -
|
2 wire
Red: +
Black: -
|
5 wire
Red: +
Black: -
Yellow: Exit button
(work with Black)
White: Door sensor,COM
Blue: Door sensor,NO
|
| Lock Delay | N / A | 0s,3s,or 6s(adjustable) | 0s,3s,or 6s(adjustable) |
| Unlock Delay | N / A |
6s
(automatically locks the
door again when no one
pushes the door within 6s
after unlocking)
|
6s
(automatically locks the
door again when no one
pushes the door within 6s
after unlocking)
|
| Door Sensor | N / A | N / A | Supports |
| Lock Cylinder | SUS304 Stainless Steel | ||
| Installation Hole Size (L*W) | 207*36(mm)(The depth of the inner pit is not less than 38mm) | ||
| Decorative Panel Size (L*W*H) | 215*41*0.7(mm) | ||
| Lock panel size (L*W*H) | 205*35*3(mm) | ||
| Gross Weight | 0.445kg | 0.719kg | 0.719kg |
| Model | LBB - 1 | UBB - 1 | LBB - 2 |
| Photo |
 |
 |
 |
| Dimensions (L*W*H) | 209*60*46(mm) | 209*60*4 6(mm) | 94*48.5*3 8(mm) |
| Application |
Frameless glass
doors with glass
thickness from 12mm to 15mm
|
Frameless glass doors; used
to install electric mortise locks;
suitable for doors with glass
thickness from 12mm to 15mm
(used with LBB - 1 only)
|
Frameless glass doors with glass
thickness from 12mm to 15mm
|
| Wiring | Stainless Steel | Stainless Steel | Stainless Steel |
| Gross Weight | 0.75kg | 0.72kg | 0.298kg |
